Nuke Input Level Transmitter with Display 4-20mA2

Nuke Input Level Transmitter with Display 4-20mA1

Nuke Input Level Transmitter with Display 4-20mA3

Nuke Input Level Transmitter with Display 4-20mA4

Nuke Input Level Transmitter with Display 4-20mA

Input liquid level transmitter LCD display, using imported core, stable and reliable suitable for fire water tank, deep well water level, water supply tower.

Real-time data display: The liquid level height can be displayed directly on the display screen in real time, which is easy for the operator to monitor at any time.
Multiple output modes: In addition to on-site display, some products also support analog or digital signal output, which is easy to connect with other control systems.
Easy installation and maintenance: The design usually takes into account convenient installation and maintenance, reducing the dependence on professional technicians.
High precision measurement: Usually has a high measurement accuracy, suitable for the application of strict liquid level requirements.
Corrosion-resistant materials: The use of corrosion-resistant materials to adapt to the measurement needs of various liquids, extend the service life.

Get A Free Quote

Input Level Transmitter with Display Description

Product functions of the plunge level meter:

Level measurement: Accurate measurement of the level height of various liquids, suitable for static and dynamic liquid environments.
Real-time display: Some models have on-site display function, real-time display of liquid level values, easy to monitor.
Signal output: Support analog signal (4-20mA) or digital signal (RS485) output, can be connected to the monitoring system.
Used in water treatment industry, water treatment industry, food and beverage industry, pharmaceutical industry, pharmaceutical industry.
The target customer groups are municipal water companies, power and energy enterprises, environmental monitoring agencies, agriculture and water management departments.

Input Level Transmitter with Display Data Sheet

Display Type Level Meter
Measure Range	0~1….200mH20
Overload Pressure	1.5times full scale
Broken Pressure	3times full scale
Accuracy	±0.2%F.S ±0.5%F.S
Stability	Typical 0.1%FS,Max 0.2%ES
Operating Temprature	-40°C-85°C
Compensating Temprature	-10°C~70°C
Medium Compatibility	Corrosive medium compatible with stainless steel Cr18Ni9Ti.316L
Wires	Two-wire	Three-wire
Signal Output	4~20mA	0/1~5Vdc	0~10Vdc
Power Supply	10~30Vdc	6~24Vdc/ac	11~30Vdc/ac
Load Resistance	(U-10)/0.02	100k
Insulation	100M @50V
Electric strength	500V@60 second
Vibration/mpact	10g/5~2000Hz，axes X/Y/Z20g sine 11ms
Elecrical connection	five level protection.lP68
Pressure Connection	Investment style:Transmission box wellhead connector sizeM27x1 5
Response Time	10ms
Pressure Type	Gauge G
Certificate	CE.Intrinsically safe E.Explosion-proof D
EMC	EMI:EN50081-1/-2 /EMS:EN50082-2

Please Contact Me for a Guote for an Input Level Meter with Digital Display

Nuke input level gauges give you more accurate level height measurement.

Get A Free Quote Now

Products Categories

Flow Measurement

Level Measurement

Pressure Measurement

Temperature Measurement

Get A Free Quote

Input Level Transmitter with Display Applications

Water treatment industry: Suitable for liquid level monitoring of sewage treatment plants, waterworks and reservoirs.
Petrochemical: Used for liquid level measurement in oil storage tanks, reactors and storage tanks to ensure production safety.
Food and beverage: Monitor the liquid level in the fermenter and storage tank to ensure process stability.
Pharmaceutical industry: Monitor liquid levels in production equipment for compliance with hygiene and quality control standards.
Power industry: Used for real-time monitoring of liquid level in boilers, cooling towers and water storage tanks.
Agricultural irrigation: Used for monitoring water conservancy projects, channels and groundwater levels.
Environmental monitoring: For rivers, lakes, reservoirs level monitoring, assessment of environmental changes.

More Information

Input level gauge tape shows China supplier source manufacturer

Nuke Intelligent Instruments is located in Nanjing, China, with a professional R & D team, deeply engaged in the instrument industry. Products have integrated electromagnetic flowmeter, vortex flowmeter, split electromagnetic flowmeter and other products, can be customized according to customer choice, patch production and software page design
