The original manufacturer of Hirschmann pressure transmitters.
Nuke Intelligent Instrument is located in Nanjing, China, with a professional R & D team, deeply engaged in the instrument industry. Products have integrated electromagnetic flowmeter, vortex flowmeter, split electromagnetic flowmeter and other products, can be customized according to customer choice and software page design
Nuke Diffused Silicon Pressure Transmitter with Digital Display and 4-20mA Pressure Sensor
The Nuke Hirschmann pressure transmitter features accurate measurement, uses imported chips and has a stable signal.
- High-precision Measurement
Accurate Measurement: By adopting advanced sensor technology and precise signal processing circuits, it can accurately measure pressure changes, ensuring the accuracy and reliability of measurement results and providing precise pressure data support for the industrial production process. - High-quality Materials and Robust Structure
Imported Chips: The core components use imported chips, which have higher performance and quality guarantees, enhancing the overall performance and reliability of the transmitter and ensuring stable operation in complex industrial environments. - Advanced Signal Processing and Transmission
Stable Signals: It conducts effective filtering, amplification, and linearization processing on the measurement signals and outputs stable standard signals, such as 4-20mA current signals or other commonly used industrial signals, ensuring the accuracy of signal transmission and anti-interference ability, so that the receiving end can accurately obtain pressure information. - Convenient Installation and Maintenance
Easy Installation: With a reasonable structural design, it is compact in size, lightweight, and has a variety of flexible installation methods. Installation options can be selected according to the actual situation on site, such as threaded connection, flange connection, etc., which greatly reduces the installation difficulty and cost and saves installation time and labor costs.
Diffused Silicon Pressure Transmitter Description
Compact pressure sensor and pressure transmitter, intelligent diffused silicon constant-pressure air pressure, water pressure and hydraulic pressure sensor.
The Hirschmann pressure transmitter has powerful functions. It can measure various pressures with high precision, has a wide measuring range and intelligent signal output, and is adaptable to harsh environments. It is also compact and lightweight in design.
It is widely used in industries such as petrochemical, electric power, water supply, and pharmaceuticals. It meets the needs for accurate pressure monitoring and control and is suitable for target customer groups like various industrial enterprises.
Diffused Silicon Pressure Transmitter Applications
| Hertzmann pressure transmitter | |||||||
| Measurement Range | 0~35Kpa-0~35MPa(Gauge pressure/ Absolute pressure),0~10Kpa | ||||||
| Overload Pressure | 1.5 time of full scales (Max.100Mpa) | ||||||
| Burst pressure | 3.0 time of full scales (Max.100Mpa) | ||||||
| Accuracy | ±0.5%F.S | ||||||
| Stabillty | <0.5%F.S/Year | ||||||
| Working Temperature | -20~+85°C | ||||||
| Storage Temperature | -40~+100°C | ||||||
| Measured Medium | All corrosive media compatible with 1Cr18Ni9Ti and NBR | ||||||
| Output Mode | Two-wired | Three-wired | Four-wired | ||||
| Output Signal | 4~20mA | 0.5~4.5V | 0~5V | 0~10V | RS485 | ||
| Power Supply | 10~30VDC | 5VDC | 12~30VDC | 24VDC | |||
| Electrical Connection | DIN43650A (Big Hirschmann), M12 waterproof outlet, M12aviation connector (3PlN,4PIN) | ||||||
| Protection Grade | IP65 /IP54 | ||||||
| Pressure Connection | G1/4, NPT1/4, R1/4, BPS1/4,G1/2,7/16-20UNF, M20*1.5 etc. | ||||||
| Pressure Form | Gauge pressure/Absolute pressure | ||||||
| Certification | RoHS,EU electrical safety standard CE | ||||||
Please Contact me if you Need the products of Hirschmann Pressure Transmitter.
Get more accurate measurements of air pressure, water pressure and hydraulic pressure.
Products Categories
Get A Free Quote
Diffused Silicon Pressure Transmitter Applications
1. Petrochemical Industry: Used in oil extraction, refining, etc. for pipeline pressure monitoring, reactor control, and tank level measurement. It ensures safe operation, prevents accidents due to abnormal pressure, and provides data for process optimization and quality control.
2. Power Industry: Applied in various power generation fields like thermal, hydro, and wind power for pressure measurement, such as boiler steam, turbine lubricant, and hydraulic system pressure monitoring.
3. Urban Water Supply & Sewage Treatment: In urban water systems, it’s for network pressure monitoring, pump station control, and tank level measurement to ensure stable water supply and quality.
4. Pharmaceutical & Food/Beverage Industries: In pharmaceutical production, it precisely controls and monitors pressure in synthesis, fermentation, etc. to meet strict quality standards.
5. Auto Manufacturing & Machining: In auto making, it measures and debugs pressure in engine test benches, braking systems. In machining, it monitors and controls pressures like cutting fluid and hydraulic fixture pressure.
